Goodwill & Company

　

　

　

　

Accessories

　

　

OHMI

　

　

V-17

Hex-wave

　

　

　

	Order No.	Point	D1	L1	D2xL2	D3xL3	Weight
	Order No.	Size	(mm)	(mm)	(mm)	(mm)	(g)
	V-17T T1x6.35x50(1.5x15,4x28)	T1	6.35	50	4x28	1.5x15	7
	V-17T T1x6.35x75(1.5x15,4x53)	T1	6.35	75	4x53	1.5x15	9
	V-17T T2x6.35x50(1.5x15,4x28)	T2	6.35	50	4x28	1.5x15	7
	V-17T T2x6.35x75(1.5x15,4x53)	T2	6.35	75	4x53	1.5x15	9
	V-17T T3x6.35x50(1.7x15,4x28)	T3	6.35	50	4x28	1.7x15	7
	V-17T T3x6.35x75(1.7x15,4x53)	T3	6.35	75	4x53	1.7x15	9
	V-17T T4x6.35x50(1.8x15,4x28)	T4	6.35	50	4x28	1.8x15	7
	V-17T T4x6.35x75(1.8x15,4x53)	T4	6.35	75	4x53	1.8x15	9
	V-17T T5x6.35x50(2x15,4x28)	T5	6.35	50	4x28	2x15	7
	V-17T T5x6.35x75(2x15,4x53)	T5	6.35	75	4x53	2x15	9

　

　

　

	Order No.	Point	D1	L1	D2	L2	Weight
	Order No.	Size	(mm)	(mm)	(mm)	(mm)	(g)
	V-17T T6x7x50(2.5x15)	T6	7	50	2.5	15	9
	V-17T T6x7x75(2.5x15)	T6	7	75	2.5	15	17
	V-17T T6x7x100(2.5x15)	T6	7	100	2.5	15	24
	V-17T T7x7x50(2.5x15)	T7	7	50	2.5	15	9
	V-17T T7x7x75(2.5x15)	T7	7	75	2.5	15	17
	V-17T T7x7x100(2.5x15)	T7	7	100	2.5	15	24
	V-17T T8x7x50(3x15)	T8	7	50	3	15	9
	V-17T T8x7x75(3x15)	T8	7	75	3	15	17
	V-17T T8x7x100(3x15)	T8	7	100	3	15	24
	V-17T T9x7x50(3.3x15) *	T9	7	50	3.3	15	*
	V-17T T9x7x75(3.3x15) *	T9	7	75	3.3	15	*
	V-17T T9x7x100(3.3x15) *	T9	7	100	3.3	15	*

　

* Custom made item.

　

　

	Order No.	Point	D1	L1	D2	L2	Weight
	Order No.	Size	(mm)	(mm)	(mm)	(mm)	(g)
	V-17T T10x7x50(3.6x15)	T10	7	50	3.6	15	10
	V-17T T10x7x75(3.6x15)	T10	7	75	3.6	15	17
	V-17T T10x7x100(3.6x15)	T10	7	100	3.6	15	25
	V-17T T15x7x50(4.3x15)	T15	7	50	4.3	15	10
	V-17T T15x7x75(4.3x15)	T15	7	75	4.3	15	18
	V-17T T15x7x100(4.3x15)	T15	7	100	4.3	15	25
	V-17T T20x7x50(5x15)	T20	7	50	5	15	11
	V-17T T20x7x75(5x15)	T20	7	75	5	15	18
	V-17T T20x7x100(5x15)	T20	7	100	5	15	26
	V-17T T20x7x150(5x15)	T20	7	150	5	15	40
	V-17T T25x7x50(5.5x15)	T25	7	50	5.5	15	11
	V-17T T25x7x75(5.5x15)	T25	7	75	5.5	15	19
	V-17T T25x7x100(5.5x15)	T25	7	100	5.5	15	26
	V-17T T25x7x150(5.5x15)	T25	7	150	5.5	15	41
	V-17T T27x7x50(6x15)	T27	7	50	6	15	12
	V-17T T27x7x75(6x15)	T27	7	75	6	15	19
	V-17T T27x7x100(6x15)	T27	7	100	6	15	26
	V-17T T27x7x150(6x15)	T27	7	150	6	15	41
	V-17T T30x7x50(6.5x15)	T30	7	50	6.5	15	12
	V-17T T30x7x75(6.5x15)	T30	7	75	6.5	15	19
	V-17T T30x7x100(6.5x15)	T30	7	100	6.5	15	27
	V-17T T30x7x150(6.5x15)	T30	7	150	6.5	15	42
	V-17T T40x7x50	T40	7	50	—	—	13
	V-17T T40x7x75	T40	7	75	—	—	20
	V-17T T40x7x100	T40	7	100	—	—	28
	V-17T T40x7x150	T40	7	150	—	—	43
	V-17T T45x8x75	T45	7	75	8	—	23
	V-17T T45x8x100	T45	7	100	8	—	33
	V-17T T50x9x75	T50	7	75	9	—	26
	V-17T T50x9x100	T50	7	100	9	—	38

　

　

　
